Schema-Versioned Helper Output Envelope

The first version of triage-gather.js emitted a bare JSON object. Add a field to the output, and consumers downstream broke silently — they kept reading the old fields, missed the new one, rendered an incomplete view, and nobody noticed until a feature relying on the new field shipped wrong. The fix wasn’t more docs. It was an envelope: every helper output gets the same wrapper, and the wrapper carries the schema version.

This post is about that envelope — what fields it has, why each one earned its place across two iterations, and what the consumer-side branching looks like.

The problem

Skills increasingly delegate gather/transform work to small helper scripts (Node, Python) that emit JSON to stdout for the skill to consume. Without an explicit envelope, every helper invents its own shape, exit-code-vs-status convention, and breakage signal. Cross-agent (Claude / Codex / Gemini) consumption magnifies the cost — each agent’s wrapper has to special-case.

Context

3B’s project-context-loader skill calls triage-gather.js to collect priorities, active rows, journal Next bullets, etc., then renders them in the triage view. Earlier iterations had the helper emit a bare object — schema changes broke the consumer silently. Adding the envelope below prevents that.

The solution

Standardize on this output shape for any helper invoked from a skill:

{
  "schema_version": "1.0.0",
  "status": "ok | partial | error | tool-missing",
  "error": null,
  "agent": "claude | codex | gemini | unknown",
  "ts": "2026-05-01T...",

  "<helper-specific fields>": "..."
}

The envelope wraps any helper-specific payload. The five fixed fields are the contract; everything inside the helper-specific block is free to change as long as the schema version reflects it.

Required envelope fields

Field	Type	Purpose
`schema_version`	semver string	Bumps on shape changes. Consumer skill reads first; aborts if it doesn’t recognize the major.
`status`	enum	Always-set one-word state. `ok` / `partial` / `error` / `tool-missing` are the standard values.
`error`	object \| null	When `status != "ok"`, populated with `{ code: string, message: string }`. Null otherwise.
`agent`	string	Helper auto-detects from env (e.g., `CODEX_PROFILE`/`GEMINI_PROFILE` env vars) so the consumer can branch.
`ts`	ISO 8601	When the helper ran. Useful for staleness checks.

Status semantics

The status enum is the most important field for cross-agent reuse — it tells the consumer how to react before parsing anything else:

Status	When to use
`ok`	All gather steps succeeded, no skipped sources
`partial`	Some sources unreadable; output has `skipped_sources` array. Skill should still consume but flag.
`error`	Internal failure. Output content is undefined. Consumer should fall back to alternative.
`tool-missing`	Helper itself cannot run (e.g., dependency CLI absent). Distinguish from `error` because consumer often has a different fallback.

Why semver and not a single integer

Skills that consume the helper care about backwards-compatibility. Bumping the major tells the consumer “your old fields may not be there”; minor says “new fields appeared, old ones still work”. Single integer collapses these.

In practice, the consumer can pin to a major and accept any minor. That makes adding new optional fields a non-event for consumers — they only need to re-test on major bumps. Single-integer schema versions force every consumer to re-validate on every bump because they can’t tell which kind of change it was.

Implementation sketch

// helper.js
const SCHEMA_VERSION = "1.0.0";

function emit(content, { status = "ok", error = null } = {}) {
  process.stdout.write(
    JSON.stringify(
      {
        schema_version: SCHEMA_VERSION,
        status,
        error,
        agent: detectAgent(),
        ts: new Date().toISOString(),
        ...content
      },
      null,
      2
    ) + "
"
  );
  process.exit(status === "error" ? 1 : 0);
}

function detectAgent() {
  if (process.env.CODEX_PROFILE) return "codex";
  if (process.env.GEMINI_PROFILE) return "gemini";
  return "claude";
}

The consumer-side branching follows the status enum directly:

Run helper. Parse JSON.
If schema_version major != expected → fall back to manual gather.
If status == "error" → log error.code/error.message; fall back.
If status == "tool-missing" → emit user-facing tool-install hint.
If status == "partial" → consume content; add "Sources skipped" footer.
If status == "ok" → consume content.

Note that tool-missing and error produce different consumer responses. A crashed helper deserves a fallback. A helper that can’t run because the underlying CLI isn’t installed deserves a user-visible install hint. Folding both into “error” loses that distinction, and the consumer ends up either too quiet (“just fell back, nothing for the user to do”) or too noisy (“install this!” on every internal crash).

Difficulties encountered

Picking the canonical status enum took two iterations. First version had ok | error only — couldn’t represent “ran, but partial”. Adding partial made the consumer-side branch correct. Adding tool-missing later distinguished “your helper can’t run because the underlying CLI isn’t installed” from “your helper crashed”. These are different fallbacks for the consumer, so they need different statuses.
error field shape: started as a string; switched to { code, message } object so consumer can dispatch on code without parsing the message.
Schema version stored at top of file as a constant. Bumping the constant + updating consumer’s version-acceptance list is the change ritual. Unit-test the helper’s emitted JSON against a captured fixture so version bumps stay deliberate.

Key points

Always include schema_version — even at 1.0.0. Future-you will thank present-you.
status is always set — even on the happy path ("ok"). Lets consumers branch without parsing the rest.
Error envelope as object, not string — consumer dispatches on error.code, not parsed message.
Auto-detect agent — helpers that run cross-agent should embed the detected agent in output so consumers can branch on it.
Stable JSON ordering — null, 2 indent + key order matters for diffing and unit-test fixtures. Don’t shuffle keys per release.

When to use this

Any Node / Python / Go helper invoked from a skill that emits JSON.
Cross-agent helpers where Claude / Codex / Gemini all consume the output.
Long-lived helpers where the output shape will evolve.

When not to use this

One-off shell pipelines that emit pre-formatted text (the consumer just pipes it).
Helpers where the output is the helper’s behavior log, not data (e.g., install scripts).

Takeaway

The envelope isn’t impressive. It’s five fields wrapped around whatever the helper actually produces. What matters is that every cross-agent helper has the same five fields in the same shape, so consumers can write one parser and reuse it everywhere.

The lesson I keep relearning: the smallest amount of structure between producers and consumers pays for itself the first time you change something. Bare JSON is fine when the helper has one consumer that you control. The moment the consumer count goes above one — three agents, in this case — the cost of “no envelope” is silent breakage. The envelope is what makes the breakage loud.
